- Terminal connector version, Change ” L ” in the Model to ” T “
- S: Sleeve bearing B: Ball bearing
- Weight: 2500gram
Product and Usage Description:
- Insulation Resistance: 10MΩ at 500VDC between lead and frame
- Dielectric Strength: 1 minute at 1500VAC/50-60Hz, current < 5mA
- Operating Temperature: -10°C to 60°C
- Operating Humidity: 20% to 85%
- Working Voltage: 85V to 125V for 110V and 190V to 250V for 220V
- Life at 25°C: Ball bearing 60,000 hours, Sleeve bearing 30,000 hours
- General value here only for reference,real specification will be met the samples, and we accept customized services.
